دیتاشیت MBR3045PT

MBR3045PT

مشخصات دیتاشیت

نام دیتاشیت MBR3045PT
حجم فایل 61.136 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت MBR3045PT

MBR3045PT Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: YFW MBR3045PT
  • Diode Configuration: Dual Common Cathode
  • Reverse Voltage (Vr): 45V
  • Forward Voltage (Vf@If): 0.58V@15A
  • Reverse Leakage Current (Ir): 8uA
  • Average Rectified Current (Io): 30A
  • Package: TO-247
  • Manufacturer: YFW
  • Series: SWITCHMODE™
  • Packaging: Tube
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 45V
  • Current - Average Rectified (Io) (per Diode): 15A
  • Voltage - Forward (Vf) (Max) @ If: 600mV @ 20A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 1mA @ 45V
  • Operating Temperature - Junction: -65°C ~ 175°C
  • Mounting Type: Through Hole
  • Package / Case: TO-218-3
  • Supplier Device Package: SOT-93
  • Base Part Number: MBR3045
