دیتاشیت MBR20200CT
مشخصات دیتاشیت
| نام دیتاشیت |
MBR20200CT
|
| حجم فایل |
89.548
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
Jiangsu Changjing Electronics Technology Co., Ltd. MBR20200CT
-
Reverse Voltage (Vr):
200V
-
Forward Voltage (Vf@If):
1V@10A
-
Average Rectified Current (Io):
10A
-
Package:
TO-220
-
Manufacturer:
Jiangsu Changjing Electronics Technology Co., Ltd.
-
Diode Configuration:
Dual Common Cathode
-
Reverse Leakage Current (Ir):
200uA@200V
-
Peak forward surge current:
150A
-
Series:
SWITCHMODE™
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
200V
-
Current - Average Rectified (Io) (per Diode):
10A
-
Voltage - Forward (Vf) (Max) @ If:
900mV @ 10A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
1mA @ 200V
-
Operating Temperature - Junction:
-65°C ~ 175°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB
-
Base Part Number:
MBR20200
