MPSA12 Datasheet

MPSA12

Datasheet specifications

Datasheet's name MPSA12
File size 49.096 KB
File type pdf
Number of pages 3

Download Datasheet MPSA12

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Transistor Type: NPN - Darlington
  • Voltage - Collector Emitter Breakdown (Max): 20V
  • Vce Saturation (Max) @ Ib, Ic: 1V @ 10µA, 10mA
  • Current - Collector Cutoff (Max): 100nA (ICBO)
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 20000 @ 10mA, 5V
  • Power - Max: 625mW
  • Frequency - Transition: -
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Supplier Device Package: TO-92-3
  • Base Part Number: MPSA12
