LM318N Datasheet

LM118/LM218/LM318

Datasheet specifications

Datasheet's name LM118/LM218/LM318
File size 1834.74 KB
File type pdf
Number of pages 27

Download Datasheet LM118/LM218/LM318

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Gain Bandwidth Product: 15MHz
  • Number of Circuits: 1
  • Current - Input Bias: 150nA
  • -3db Bandwidth: 15MHz
  • Base Part Number: LM318
  • Operating Temperature: 0°C ~ 70°C
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Current - Supply: 5mA
  • Supplier Device Package: 8-PDIP
  • Part Status: Obsolete
  • Amplifier Type: General Purpose
  • Series: -
  • Manufacturer: Texas Instruments
  • Slew Rate: 70V/µs
  • Voltage - Supply, Single/Dual (±): 10V ~ 40V, ±5V ~ 20V
  • Voltage - Input Offset: 4mV
  • Packaging: Tube
  • Mounting Type: Through Hole
  • Output Type: -
  • detail: General Purpose Amplifier 1 Circuit 8-PDIP
