SN74HC595N Datasheet

SN74HC595N

Datasheet specifications

Datasheet's name SN74HC595N
File size 85.497 KB
File type pdf
Number of pages 36

Download Datasheet SN74HC595N

Download Datasheet

Other documentations

SN54/SN74HC595 39 pages

Technical specifications

  • RoHS: true
  • Series: 74HC
  • Category: Logic ICs/Shifting Register
  • Function: 串行至并行或串行
  • Datasheet: Texas Instruments SN74HC595N
  • Output Type: Tri-State
  • Supply Voltage: 2V~6V
  • Operating Temperature: 40°C~+85°C
  • Number of Bits per Element: 8
  • Package: DIP-16
  • Manufacturer: Texas Instruments
  • Supplier Device Package: 16-PDIP
  • Base Part Number: SN74HC5
  • Mounting Type: Through Hole
  • Packaging: Tube
  • Voltage - Supply: 2V ~ 6V
  • Number of Elements: 1
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Part Status: Active
  • Logic Type: Shift Register
