دیتاشیت BU406
مشخصات دیتاشیت
| نام دیتاشیت |
BU406, BU407
|
| حجم فایل |
83.221
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
ISC BU406
-
Package:
TO-220
-
Manufacturer:
ISC
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
7A
-
Power Dissipation (Pd):
60W
-
Transition Frequency (fT):
10MHz
-
DC Current Gain (hFE@Ic,Vce):
40@2A,5V
-
Collector Cut-Off Current (Icbo):
-
-
Collector-Emitter Breakdown Voltage (Vceo):
200V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
1V@5A,500mA
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Current - Collector (Ic) (Max):
7A
-
Voltage - Collector Emitter Breakdown (Max):
200V
-
Vce Saturation (Max) @ Ib, Ic:
1V @ 500mA, 5A
-
Current - Collector Cutoff (Max):
5mA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
-
-
Power - Max:
60W
-
Frequency - Transition:
10MHz
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220-3
-
Base Part Number:
BU406
