دیتاشیت STGW38IH130D

STGW38IH130D

مشخصات دیتاشیت

نام دیتاشیت STGW38IH130D
حجم فایل 845.333 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت STGW38IH130D

STGW38IH130D Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: PowerMESH™
  • Packaging: Tube
  • Part Status: Obsolete
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 1300V
  • Current - Collector (Ic) (Max): 63A
  • Current - Collector Pulsed (Icm): 125A
  • Vce(on) (Max) @ Vge, Ic: 2.8V @ 15V, 20A
  • Power - Max: 250W
  • Switching Energy: 3.4mJ (off)
  • Input Type: Standard
  • Gate Charge: 127nC
  • Td (on/off) @ 25°C: -/284ns
  • Test Condition: 960V, 20A, 10Ohm, 15V
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-247-3
  • Supplier Device Package: TO-247 Long Leads
  • Base Part Number: STGW38
  • detail: IGBT 1300V 63A 250W Through Hole TO-247 Long Leads
