دیتاشیت 1N4004
مشخصات دیتاشیت
| نام دیتاشیت | 1N4001-4007 Datasheet |
|---|---|
| حجم فایل | 165.547 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت 1N4001-4007 Datasheet |
1N4001-4007 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - General Purpose
- Datasheet: Chongqing Pingwei Tech 1N4004
- Diode Configuration: Single
- Reverse Voltage (Vr): 400V
- Forward Voltage (Vf@If): 1.3V@3A
- Reverse Leakage Current: 5uA@400V
- Average Rectified Current (Io): 1A
- Package: DO-41
- Manufacturer: Chongqing Pingwei Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 400V
- Current - Average Rectified (Io): 1A
- Voltage - Forward (Vf) (Max) @ If: 1.1V @ 1A
- Speed: Standard Recovery >500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 5µA @ 400V
- Capacitance @ Vr, F: 15pF @ 4V, 1MHz
- Mounting Type: Through Hole
- Package / Case: DO-204AL, DO-41, Axial
- Supplier Device Package: DO-204AL (DO-41)
- Operating Temperature - Junction: -55°C ~ 175°C
- Base Part Number: 1N4004
- detail: Diode Standard 400V 1A Through Hole DO-204AL (DO-41)
