دیتاشیت NJW0302G

مشخصات دیتاشیت

دانلود دیتاشیت NJW0281G, NJW0302G	NJW0281G, NJW0302G Datasheet

RoHS: true
Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
Datasheet: SPTECH NJW0302G
Transistor Type: PNP
Operating Temperature: +150°C@(Tj)
Collector Current (Ic): 15A
Power Dissipation (Pd): 150W
Transition Frequency (fT): -
DC Current Gain (hFE@Ic,Vce): 75@3A,5V
Collector Cut-Off Current (Icbo): 50mA
Collector-Emitter Breakdown Voltage (Vceo): 250V
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 600mV@10A,1A
Package: TO-3PN
Manufacturer: SPTECH
Series: -
Packaging: Tube
Part Status: Active
Current - Collector (Ic) (Max): 15A
Voltage - Collector Emitter Breakdown (Max): 250V
Vce Saturation (Max) @ Ib, Ic: 1V @ 500mA, 5A
Current - Collector Cutoff (Max): 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 75 @ 3A, 5V
Power - Max: 150W
Frequency - Transition: 30MHz
Mounting Type: Through Hole
Package / Case: TO-3P-3, SC-65-3
Supplier Device Package: TO-3P-3L
Base Part Number: NJW03
detail: Bipolar (BJT) Transistor PNP 250V 15A 30MHz 150W Through Hole TO-3P-3L
