L7912CV 数据手册
其他文档
L79xxC 24 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: STMicroelectronics L7912CV
- Output Type: Fixed
- Output Current: 1.5A
- Output Voltage: 12V
- Dropout Voltage: 1.1V@(1A)
- Output Polarity: Negative
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: 0°C~+125°C
- Quiescent Current (Ground Current): 3mA
- Power Supply Rejection Ratio (PSRR): 60dB@(120Hz)
- Package: TO-220
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Negative
- Number of Regulators: 1
- Voltage - Input (Max): -35V
- Voltage - Output (Min/Fixed): -12V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 1.1V @ 1A (Typ)
- Current - Output: 1.5A
- Current - Quiescent (Iq): 3mA
- PSRR: 60dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: L7912
