دیتاشیت 1N4001

1N4001-4007 Datasheet

مشخصات دیتاشیت

نام دیتاشیت 1N4001-4007 Datasheet
حجم فایل 165.547 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت 1N4001-4007 Datasheet

1N4001-4007 Datasheet Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 50V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 1.1V @ 1A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 5µA @ 50V
  • Capacitance @ Vr, F: 15pF @ 4V, 1MHz
  • Mounting Type: Through Hole
  • Package / Case: DO-204AL, DO-41, Axial
  • Supplier Device Package: DO-204AL (DO-41)
  • Operating Temperature - Junction: -55°C ~ 175°C
  • Base Part Number: 1N4001
  • detail: Diode Standard 50V 1A Through Hole DO-204AL (DO-41)
