دیتاشیت DSEK60-06A
مشخصات دیتاشیت
| نام دیتاشیت |
DSEK60-06A
|
| حجم فایل |
49.331
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
Littelfuse/IXYS DSEK60-06A
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
600V
-
Operating Temperature:
-40°C~+150°C@(Tvj)
-
Forward Voltage (Vf@If):
1.81V@74A
-
Reverse Leakage Current:
100uA@600V
-
Reverse Recovery Time (trr):
90ns
-
Average Rectified Current (Io):
30A
-
Package:
TO-247-3
-
Manufacturer:
IXYS
-
Series:
FRED
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
600V
-
Current - Average Rectified (Io) (per Diode):
30A
-
Voltage - Forward (Vf) (Max) @ If:
1.6V @ 37A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
100µA @ 600V
-
Operating Temperature - Junction:
-40°C ~ 150°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-3P-3 Full Pack
-
Supplier Device Package:
TO-247AD
-
detail:
Diode Array 1 Pair Common Cathode Standard 600V 30A Through Hole TO-3P-3 Full Pack
