دیتاشیت LM393P
مشخصات دیتاشیت
| نام دیتاشیت | LM193,293,393(A), 2903(V) Datasheet |
|---|---|
| حجم فایل | 2085.732 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت LM193,293,393(A), 2903(V) Datasheet |
LM193,293,393(A), 2903(V) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments LM393P
- Output Type: 开集;轨到轨
- Supply Current: 2.5mA
- Supply Voltage: 2V~36V;1V~18V
- Number of Elements: 2
- Operating Temperature: 0°C~+70°C
- Input Bias Current (Ib): 0.25uA
- Input Offset Voltage (Vos): 5mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): -
- Package: DIP-8
- Manufacturer: Texas Instruments
- Package / Case: 8-DIP (0.300", 7.62mm)
- Propagation Delay (Max): -
- Current - Quiescent (Max): 2.5mA
- Voltage - Input Offset (Max): 5mV @ 30V
- Part Status: Active
- Current - Output (Typ): 20mA
- Current - Input Bias (Max): 0.25µA @ 5V
- Packaging: Tube
- Type: Differential
- CMRR, PSRR (Typ): -
- Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
- Series: -
- Base Part Number: LM393
- Supplier Device Package: 8-PDIP
- Mounting Type: Through Hole
- Hysteresis: -
