- دیتاشیت MMBF170
MMBF170 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MMBF170 |
|---|---|
| حجم فایل | 62.318 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت MMBF170 |
دانلود دیتاشیت |
|---|
سایر مستندات
BS170, MMBF170 14 pages
MMBF170 6 pages
مشخصات فنی
- RoHS: true
- Type: N Channel
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Datasheet: onsemi MMBF170
- Operating Temperature: -55°C~+150°C@(Tj)
- Power Dissipation (Pd): 300mW
- Total Gate Charge (Qg@Vgs): -
- Drain Source Voltage (Vdss): 60V
- Input Capacitance (Ciss@Vds): 40pF@10V
- Continuous Drain Current (Id): 500mA
- Gate Threshold Voltage (Vgs(th)@Id): 3V@1mA
- Reverse Transfer Capacitance (Crss@Vds): 7pF@10V
- Drain Source On Resistance (RDS(on)@Vgs,Id): 1.2Ω@10V,200mA
- Package: SOT-23(TO-236)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 60V
- Current - Continuous Drain (Id) @ 25°C: 500mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 5Ohm @ 200mA, 10V
- Vgs(th) (Max) @ Id: 3V @ 1mA
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 40pF @ 10V
- FET Feature: -
- Power Dissipation (Max): 300mW (Ta)
- Mounting Type: Surface Mount
- Supplier Device Package: SOT-23
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Base Part Number: MMBF17
