TIP31C دیتاشیت

TIP31C

مشخصات دیتاشیت

نام دیتاشیت TIP31C
حجم فایل 56.732 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت TIP31C

دانلود دیتاشیت

سایر مستندات

TO220B03 Pkg Drawing 1 pages

TIP31(A,B,C), TIP32(A,B,C) 7 pages

TIP31C 10 pages

TIP31C 4 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
  • Datasheet: Jiangsu Changjing Electronics Technology Co., Ltd. TIP31C
  • Package: TO-220
  • Manufacturer: Jiangsu Changjing Electronics Technology Co., Ltd.
  • Transistor Type: NPN
  • Operating Temperature: +150°C@(Tj)
  • Collector Current (Ic): 3A
  • Power Dissipation (Pd): 2W
  • Transition Frequency (fT): -
  • DC Current Gain (hFE@Ic,Vce): 10@3A,4V
  • Collector Cut-Off Current (Icbo): 300uA
  • Collector-Emitter Breakdown Voltage (Vceo): 100V
  • Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 1.2V@3A,375mA
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Current - Collector (Ic) (Max): 3A
  • Voltage - Collector Emitter Breakdown (Max): 100V
  • Vce Saturation (Max) @ Ib, Ic: 1.2V @ 375mA, 3A
  • Current - Collector Cutoff (Max): 300µA
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 10 @ 3A, 4V
  • Power - Max: 2W
  • Frequency - Transition: 3MHz
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: TIP31
