LM2596S-ADJ Datasheet
Datasheet specifications
|
Datasheet's name
|
LM2596S-ADJ
|
|
File size
|
48.745
KB
|
|
File type
|
pdf
|
|
Number of pages
|
12
|
Technical specifications
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
UMW(Youtai Semiconductor Co., Ltd.) LM2596S-ADJ
-
Output Type:
Adjustable
-
Input Voltage:
40V
-
Output Voltage:
1.2V~37V
-
Number of Outputs:
1
-
Switching Frequency:
150kHz
-
Output Current (Max):
3A
-
Operating Temperature:
-40°C~+125°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
TO-263-5
-
Manufacturer:
UMW(Youtai Semiconductor Co., Ltd.)
-
Quiescent Current (Iq):
10mA
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Output Configuration:
Positive
-
Base Part Number:
LM2596
-
Packaging:
Tube
-
Frequency - Switching:
150kHz
-
Supplier Device Package:
DDPAK/TO-263-5
-
Part Status:
Obsolete
-
Current - Output:
3A
-
Series:
SIMPLE SWITCHER®
-
Voltage - Input (Max):
40V
-
Synchronous Rectifier:
No
-
Voltage - Output (Min/Fixed):
1.2V
-
Voltage - Input (Min):
4.5V
-
Mounting Type:
Surface Mount
-
Voltage - Output (Max):
37V
