TL494 Datasheet Datasheet

TL494 Datasheet

Datasheet specifications

Datasheet's name TL494 Datasheet
File size 1424.251 KB
File type pdf
Number of pages 33

Download Datasheet TL494 Datasheet

Download Datasheet

Other documentations

TL494IN 33 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Controllers
  • Function: boost converterType;Step-down type;Buck-boost type
  • Topology: Step-down;Boost;Flyback;Forward;Full-Bridge;Half-Bridge;Push-pull
  • Datasheet: Texas Instruments TL494CN
  • Input Voltage: 7V~40V
  • Duty Cycle (Max): 45%
  • Number of Outputs: 2
  • Switching Frequency: 300kHz
  • Operating Temperature: 0°C~+70°C@(TA)
  • Synchronous Rectification: NO
  • Package: DIP-16
  • Manufacturer: Texas Instruments
  • Part Status: Active
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Packaging: Tube
  • Frequency - Switching: 1kHz ~ 300kHz
  • Supplier Device Package: 16-PDIP
  • Serial Interfaces: -
  • Synchronous Rectifier: No
  • Clock Sync: No
  • Mounting Type: Through Hole
  • Output Configuration: Positive
  • Base Part Number: TL494
  • Series: -
  • Output Type: Transistor Driver
  • Control Features: Dead Time Control, Frequency Control
  • Output Phases: 1
  • Voltage - Supply (Vcc/Vdd): 7V ~ 40V
  • detail: Buck, Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-PDIP
