دیتاشیت LM339N

مشخصات دیتاشیت

دانلود دیتاشیت LM139, 239, 339	LM139, 239, 339 Datasheet

RoHS: true
Category: Operational Amplifier/Comparator/Comparators
Datasheet: HGSEMI LM339N
Package: DIP-14
Manufacturer: HGSEMI
Output Type: 开集;轨到轨
Supply Current: 2.5mA
Supply Voltage: 2V~30V;1V~15V
Number of Elements: 4
Operating Temperature: 0°C~+70°C
Input Bias Current (Ib): 0.25uA
Input Offset Voltage (Vos): 5mV
Input Hysteresis Voltage (Vhys): -
Common Mode Rejection Ratio (CMRR): -
Series: -
Packaging: Tube
Part Status: Obsolete
Type: General Purpose
Voltage - Supply, Single/Dual (±): 2V ~ 32V, ±1V ~ 16V
Voltage - Input Offset (Max): 5mV @ 30V
Current - Input Bias (Max): 0.25µA @ 5V
Current - Output (Typ): 16mA @ 5V
Current - Quiescent (Max): 2.5mA
CMRR, PSRR (Typ): -
Propagation Delay (Max): -
Hysteresis: -
Package / Case: 14-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Supplier Device Package: 14-DIP
Base Part Number: LM339
detail: Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL 14-DIP
