TIP41 Datasheet
Datasheet specifications
| Datasheet's name | TIP41 |
|---|---|
| File size | 110.257 KB |
| File type | |
| Number of pages | 4 |
Download Datasheet TIP41 |
Download Datasheet |
|---|
Other documentations
TO220B03 Pkg Drawing 1 pages
TIP41 4 pages
Technical specifications
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Bulk
- Part Status: Obsolete
- Transistor Type: NPN
- Current - Collector (Ic) (Max): 6A
- Voltage - Collector Emitter Breakdown (Max): 40V
- Vce Saturation (Max) @ Ib, Ic: 1.5V @ 600mA, 6A
- Current - Collector Cutoff (Max): 700µA
- DC Current Gain (hFE) (Min) @ Ic, Vce: 15 @ 3A, 4V
- Power - Max: 2W
- Frequency - Transition: 3MHz
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220-3
- Base Part Number: TIP41
