دیتاشیت L6203

مشخصات دیتاشیت

دانلود دیتاشیت L620x	L620x Datasheet

Manufacturer: STMicroelectronics
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Half Bridge (2)
Applications: DC Motors, General Purpose
Interface: Logic
Load Type: Inductive
Technology: BCDMOS
Rds On (Typ): 300mOhm
Current - Output / Channel: 4A
Current - Peak Output: -
Voltage - Supply: 12V ~ 48V
Voltage - Load: 12V ~ 48V
Operating Temperature: -40°C ~ 150°C (TJ)
Features: Bootstrap Circuit
Fault Protection: Over Temperature
Mounting Type: Through Hole
Package / Case: Multiwatt-11 (Vertical, Bent and Staggered Leads)
Supplier Device Package: 11-Multiwatt
Base Part Number: L6203
detail: Half Bridge (2) Driver DC Motors, General Purpose BCDMOS 11-Multiwatt
