دیتاشیت UF4007

UF4001 - UF4007

مشخصات دیتاشیت

نام دیتاشیت UF4001 - UF4007
حجم فایل 271.227 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت UF4001 - UF4007

UF4001 - UF4007 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: MDD(Microdiode Electronics) UF4007
  • Diode Configuration: -
  • Reverse Voltage (Vr): 1kV
  • Operating Temperature: -50°C~+150°C@(Tj)
  • Forward Voltage (Vf@If): 1.7V@1A
  • Reverse Leakage Current: 5uA@1kV
  • Reverse Recovery Time (trr): 75ns
  • Average Rectified Current (Io): 1A
  • Package: DO-41
  • Manufacturer: MDD(Microdiode Electronics)
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 1000V
  • Current - Average Rectified (Io): 1A
  • Voltage - Forward (Vf) (Max) @ If: 1.7V @ 1A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 10µA @ 1000V
  • Capacitance @ Vr, F: 17pF @ 4V, 1MHz
  • Mounting Type: Through Hole
  • Package / Case: DO-204AL, DO-41, Axial
  • Supplier Device Package: DO-204AL (DO-41)
  • Operating Temperature - Junction: -65°C ~ 150°C
  • Base Part Number: UF400
