دیتاشیت 1N5408

1N5408

مشخصات دیتاشیت

نام دیتاشیت 1N5408
حجم فایل 81.673 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

دانلود دیتاشیت 1N5408

1N5408 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: (DIOTEC) 1N5408
  • Diode Configuration: -
  • Reverse Voltage (Vr): 1kV
  • Forward Voltage (Vf@If): 1.2V@3A
  • Reverse Leakage Current: 5uA@1kV
  • Average Rectified Current (Io): 3A
  • Package: DO-201
  • Manufacturer: (DIOTEC)
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 1000V
  • Current - Average Rectified (Io): 3A
  • Voltage - Forward (Vf) (Max) @ If: 1.2V @ 3A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 5µA @ 1000V
  • Capacitance @ Vr, F: 30pF @ 4V, 1MHz
  • Mounting Type: Through Hole
  • Package / Case: DO-201AD, Axial
  • Supplier Device Package: DO-201AD
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: 1N5408
