دیتاشیت TIP127

مشخصات دیتاشیت

دانلود دیتاشیت TIP120-122, TIP125-127	TIP120-122, TIP125-127 Datasheet

RoHS: true
Category: Triode/MOS Tube/Transistor/Darlington Transistors
Datasheet: Foshan Blue Rocket Elec TIP127
Package: TO-220
Manufacturer: Foshan Blue Rocket Elec
Transistor Type: -
Collector Current (Ic): -
Power Dissipation (Pd): -
Transition Frequency (fT): -
Collector Cut-Off Current (Icbo): -
Collector-Emitter Breakdown Voltage (Vceo): -
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): -
Operating Temperature: +150°C@(Tj)
DC current gain (hFE@Vce,Ic): 1000@3V,3A
Collector-emitter voltage (Vceo): 100V
Collector cut-off current (Icbo@Vcb): 500uA
Series: -
Packaging: Tube
Part Status: Active
Current - Collector (Ic) (Max): 5A
Voltage - Collector Emitter Breakdown (Max): 100V
Vce Saturation (Max) @ Ib, Ic: 4V @ 20mA, 5A
Current - Collector Cutoff (Max): 500µA
DC Current Gain (hFE) (Min) @ Ic, Vce: 1000 @ 3A, 3V
Power - Max: 2W
Frequency - Transition: -
Mounting Type: Through Hole
Package / Case: TO-220-3
Supplier Device Package: TO-220AB
Base Part Number: TIP127
detail: Bipolar (BJT) Transistor PNP - Darlington 100V 5A 2W Through Hole TO-220AB
