دیتاشیت BD139

BD135G,137G,139G

مشخصات دیتاشیت

نام دیتاشیت BD135G,137G,139G
حجم فایل 82.355 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت BD135G,137G,139G

BD135G,137G,139G Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Transistor Type: NPN
  • Current - Collector (Ic) (Max): 1.5A
  • Voltage - Collector Emitter Breakdown (Max): 80V
  • Vce Saturation (Max) @ Ib, Ic: 500mV @ 50mA, 500mA
  • Current - Collector Cutoff (Max): 100nA (ICBO)
  • DC Current Gain (hFE) (Min) @ Ic, Vce: 40 @ 150mA, 2V
  • Power - Max: 1.25W
  • Frequency - Transition: -
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-225AA, TO-126-3
  • Supplier Device Package: TO-225AA
  • Base Part Number: BD139
