دیتاشیت LM317T
مشخصات دیتاشیت
| نام دیتاشیت | LM317, NCV317 Datasheet |
|---|---|
| حجم فایل | 299.326 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت LM317, NCV317 Datasheet |
LM317, NCV317 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: ISC LM317T
- Package: TO-220
- Manufacturer: ISC
- Output Type: Adjustable
- Output Current: 1.5A
- Output Voltage: 1.2V~37V
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 40V
- Operating Temperature: 0°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 12mA
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 1.2V
- Voltage - Output (Max): 37V
- Voltage Dropout (Max): -
- Current - Output: 1.5A
- PSRR: 75dB ~ 60dB (120Hz)
- Control Features: -
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220-3
- Base Part Number: LM317
- detail: Linear Voltage Regulator IC 1 Output 1.5A TO-220-3
