دیتاشیت L298N

L298

مشخصات دیتاشیت

نام دیتاشیت L298
حجم فایل 613.749 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت L298

L298 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: HGSEMI L298N
  • Package: Multiwatt-15
  • Manufacturer: HGSEMI
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Half Bridge (4)
  • Applications: DC Motors, Relays, Solenoids, Stepper Motors
  • Interface: Logic
  • Load Type: Inductive
  • Technology: Bipolar
  • Rds On (Typ): -
  • Current - Output / Channel: -
  • Current - Peak Output: 2A
  • Voltage - Supply: 4.5V ~ 7V
  • Voltage - Load: 4.8V ~ 46V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Features: -
  • Fault Protection: Current Limiting, Over Temperature
  • Mounting Type: Through Hole
  • Package / Case: Multiwatt-15 (Vertical, Bent and Staggered Leads)
  • Supplier Device Package: 15-Multiwatt
  • Base Part Number: L298
