دیتاشیت LM358DR2G
مشخصات دیتاشیت
| نام دیتاشیت | LM158,258,358(A),2904(V) Datasheet |
|---|---|
| حجم فایل | 3380.794 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 56 |
دانلود دیتاشیت LM158,258,358(A),2904(V) Datasheet |
LM158,258,358(A),2904(V) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: onsemi LM358DR2G
- -3db Bandwidth: -
- Output Current: 40mA
- Supply Current: 1.5mA
- Number of Circuits: 2
- Operating Temperature: 0°C~+70°C
- Current - Input Bias(Ib): 45nA
- Gain Bandwidth Product(GBP): 1MHz
- Package: SOP-8
- Manufacturer: onsemi
- Packaging: Cut Tape (CT)
- Base Part Number: LM358
- Amplifier Type: General Purpose
- Slew Rate: 0.3V/µs
- Current - Input Bias: 20nA
- Series: -
- Output Type: -
- Voltage - Supply, Single/Dual (±): 3V ~ 32V, ±1.5V ~ 16V
- Current - Output / Channel: 30mA
- Supplier Device Package: 8-SOIC
- Gain Bandwidth Product: 700kHz
- Voltage - Input Offset: 3mV
- Part Status: Active
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Current - Supply: 1mA
- detail: General Purpose Amplifier 2 Circuit 8-SOIC
