دیتاشیت SN74LVC2G125DCUR

SN74LVC2G125

مشخصات دیتاشیت

نام دیتاشیت SN74LVC2G125
حجم فایل 1096.705 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت SN74LVC2G125

SN74LVC2G125 Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Buffer/Driver/Transceiver
  • Datasheet: Texas Instruments SN74LVC2G125DCUR
  • Input type: -
  • output type: Tri-State
  • Sink Current: 32mA
  • Source Current: 32mA
  • Supply Voltage: 1.65V~5.5V
  • Operating Temperature: -40°C~+125°C
  • Package: VSON-8(2x2.3)
  • Manufacturer: Texas Instruments
  • Number of Elements: 2
  • Packaging: Cut Tape (CT)
  • Base Part Number: SN74LVC2G
  • Package / Case: 8-VFSOP (0.091", 2.30mm Width)
  • Number of Bits per Element: 1
  • Voltage - Supply: 1.65V ~ 5.5V
  • Mounting Type: Surface Mount
  • Series: 74LVC
  • Supplier Device Package: 8-VSSOP
  • Logic Type: Buffer, Non-Inverting
  • Current - Output High, Low: 32mA, 32mA
  • Part Status: Active
