دیتاشیت SN74HC540N

مشخصات دیتاشیت

دانلود دیتاشیت SN54HC540, SN74HC540	SN54HC540, SN74HC540 Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74HC540N
output type: Tri-State
Logic Family: 74HC
Sink Current: 7.8mA
Source Current: 7.8mA
Supply Voltage: 2V~6V
Operating Temperature: -40°C~+85°C
Number of Bits per Element: 8
Package: PDIP-20
Manufacturer: Texas Instruments
Number of Elements: 1
Voltage - Supply: 2V ~ 6V
Input Type: -
Mounting Type: Through Hole
Packaging: Tube
Package / Case: 20-DIP (0.300", 7.62mm)
Part Status: Active
Current - Output High, Low: 7.8mA, 7.8mA
Series: 74HC
Supplier Device Package: 20-PDIP
Logic Type: Buffer, Inverting
Base Part Number: SN74HC5
detail: Buffer, Inverting 1 Element 8 Bit per Element 3-State Output 20-PDIP
