دیتاشیت T435-600T

T4 Series Datasheet

مشخصات دیتاشیت

نام دیتاشیت T4 Series Datasheet
حجم فایل 498.286 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت T4 Series Datasheet

T4 Series Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: 1个双向可控硅
  • Datasheet: STMicroelectronics T435-600T
  • Holding Current (Ih): 35mA
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Gate Trigger Current(Igt): 35mA
  • Gate Trigger Voltage (Vgt): 1.3V
  • RMS On-State Current(It (rms)): 4A
  • Peak Repetitive Off?State Voltage (Vdrm): 600V
  • Package: TO-220
  • Manufacturer: STMicroelectronics
  • Series: Snubberless™
  • Packaging: Tube
  • Part Status: Active
  • Triac Type: Alternistor - Snubberless
  • Voltage - Off State: 600V
  • Current - On State (It (RMS)) (Max): 4A
  • Voltage - Gate Trigger (Vgt) (Max): 1.3V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 30A, 31A
  • Current - Gate Trigger (Igt) (Max): 35mA
  • Current - Hold (Ih) (Max): 35mA
  • Configuration: Single
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: T435
