دیتاشیت TPS79230DBVR

TSP79201, 25, 28, 30

مشخصات دیتاشیت

نام دیتاشیت TSP79201, 25, 28, 30
حجم فایل 1130.751 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت TSP79201, 25, 28, 30

TSP79201, 25, 28, 30 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TPS79230DBVR
  • Output Current: 100mA
  • Output Voltage: 3V
  • Dropout Voltage: 0.1V@(100mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+85°C
  • Quiescent Current (Ground Current): 250uA
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Base Part Number: TPS792
  • Supplier Device Package: SOT-23-5
  • Voltage - Output (Max): -
  • Output Configuration: Positive
  • Current - Quiescent (Iq): 250µA
  • Output Type: Fixed
  • PSRR: 70dB ~ 47dB (100Hz ~ 100kHz)
  • Voltage Dropout (Max): 0.1V @ 100mA
  • Number of Regulators: 1
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Min/Fixed): 3V
  • Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
  • Series: -
  • Voltage - Input (Max): 5.5V
  • Current - Output: 100mA
  • Part Status: Active
  • Package / Case: SC-74A, SOT-753
  • Control Features: Enable
  • detail: Linear Voltage Regulator IC 1 Output 100mA SOT-23-5
