TPSM53603RDAR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPSM53603RDAR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Power Modules
Datasheet: Texas Instruments TPSM53603RDAR
Output Channel: 1
Output Voltage: 1V~7V
Input Voltage(DC): 3.8V~36V
Output Current (Max): 3A
Conversion Efficiency: 95%
Package: B3QFN-15
Manufacturer: Texas Instruments
Type: Non-Isolated PoL Module
Voltage - Output 2: -
Voltage - Output 3: -
Applications: ITE (Commercial)
Approval Agency: -
Series: -
Voltage - Output 4: -
Current - Output (Max): 3A
Voltage - Output 1: 1 ~ 7V
Supplier Device Package: 15-B3QFN (5x5.5)
Voltage - Input (Min): 3.8V
Part Status: Active
Base Part Number: TPSM53
Features: Adjustable Output
Efficiency: 95%
Operating Temperature: -40°C ~ 105°C
Mounting Type: Surface Mount
Voltage - Input (Max): 36V
Number of Outputs: 1
Size / Dimension: 0.22" L x 0.20" W x 0.16" H (5.5mm x 5.0mm x 4.1mm)
Control Features: Enable, Active High
Package / Case: 14-PowerBQFN Module
detail: Non-Isolated PoL Module DC DC Converter 1 Output 1 ~ 7V 3A 3.8V - 36V Input
