دیتاشیت SN74AS374N

مشخصات دیتاشیت

دانلود دیتاشیت SN54/74(ALS,AS)374(A)	SN54/74(ALS,AS)374(A) Datasheet

RoHS: true
Type: D-Type
Series: 74AS
Category: Logic ICs/Flip Flops
Function: Standard
Datasheet: Texas Instruments SN74AS374N
Output Type: Tri-State;Non-Inverted
Sink Current: 48mA
Trigger Type: 上升沿
Source Current: 15mA
Supply Voltage: 4.5V~5.5V
Clock Frequency: 125MHz
Input Capacitance: -
Number of Channels: 8
Operating Temperature: 0°C~+70°C
Quiescent Current (Iq): 120mA
Maximum Propagation Delay: 9ns@5V,50pF
Package: PDIP-20
Manufacturer: Texas Instruments
Max Propagation Delay @ V, Max CL: 9ns @ 5V, 50pF
Number of Elements: 1
Package / Case: 20-DIP (0.300", 7.62mm)
Current - Quiescent (Iq): 120mA
Base Part Number: SN74AS3
Supplier Device Package: 20-PDIP
Number of Bits per Element: 8
Packaging: Tube
Current - Output High, Low: 15mA, 48mA
Mounting Type: Through Hole
Voltage - Supply: 4.5V ~ 5.5V
Part Status: Active
detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-DIP (0.300", 7.62mm)
