دیتاشیت ADG1633BRUZ
مشخصات دیتاشیت
| نام دیتاشیت |
ADG1633,34
|
| حجم فایل |
445.002
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
19
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG1633BRUZ
-
Turn-on time:
38ns
-
Turn-off time:
152ns
-
Supply Voltage:
3.3V~16V
-
Switch Circuit:
SPDT(SPDT)
-
Number of Channels:
3
-
On-State Resistance (Max):
4.5Ω
-
Package:
TSSOP-16
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Number of Circuits:
3
-
Channel-to-Channel Matching (ΔRon):
120mOhm
-
Voltage - Supply, Single (V+):
3.3V ~ 16V
-
Voltage - Supply, Dual (V±):
±3.3V ~ 8V
-
Switch Time (Ton, Toff) (Max):
38ns, 152ns
-
-3db Bandwidth:
109MHz
-
Charge Injection:
-12.4pC
-
Channel Capacitance (CS(off), CD(off)):
19pF, 32pF
-
Current - Leakage (IS(off)) (Max):
100pA
-
Crosstalk:
-64dB @ 1MHz
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Supplier Device Package:
16-TSSOP
-
Base Part Number:
ADG1633
-
detail:
3 Circuit IC Switch 2:1 4.5Ohm 16-TSSOP
