دیتاشیت ADP2441ACPZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP2441
|
| حجم فایل |
1544.982
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
32
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Analog Devices ADP2441ACPZ-R7
-
Output Type:
Adjustable
-
Input Voltage:
4.5V~36V
-
Output Voltage:
0.6V~32.4V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
1A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
LFCSP-12-WQ
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
4.5V
-
Voltage - Input (Max):
36V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
32.4V
-
Current - Output:
1A
-
Frequency - Switching:
300kHz ~ 1MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
12-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
12-LFCSP-WQ (3x3)
-
Base Part Number:
ADP2441
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 1A 12-WFQFN Exposed Pad, CSP
