دیتاشیت LM224DR
مشخصات دیتاشیت
| نام دیتاشیت | LM124,224,324,2902 |
|---|---|
| حجم فایل | 1851.711 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 41 |
دانلود دیتاشیت LM124,224,324,2902 |
LM124,224,324,2902 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: UMW(Youtai Semiconductor Co., Ltd.) LM224DR
- Package: SOP-14
- Manufacturer: UMW(Youtai Semiconductor Co., Ltd.)
- -3db Bandwidth: -
- Output Current: 30mA
- Supply Current: 1.4mA
- Number of Circuits: 4
- Operating Temperature: -25°C~+85°C
- Current - Input Bias(Ib): 20nA
- Gain Bandwidth Product(GBP): 1.2MHz
- Voltage - Input Offset: 3mV
- Current - Supply: 1.4mA
- Mounting Type: Surface Mount
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Amplifier Type: General Purpose
- Series: -
- Base Part Number: LM224
- Part Status: Active
- Gain Bandwidth Product: 1.2MHz
- Current - Input Bias: 20nA
- Voltage - Supply, Single/Dual (±): 3V ~ 32V, ±1.5V ~ 16V
- Packaging: Cut Tape (CT)
- Output Type: -
- Supplier Device Package: 14-SOIC
- Slew Rate: 0.5V/µs
- Current - Output / Channel: 40mA
- detail: General Purpose Amplifier 4 Circuit 14-SOIC
