TPS2812P 数据手册
其他文档
TPS2811-15 40 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: Texas Instruments TPS2812P
- Fall Time: 15ns
- Load Type: MOSFET
- Rise Time: 14ns
- Supply Voltage: 4V~14V
- Number of Drivers: 2
- Driven Configuration: Low Side
- Operating Temperature: -40°C~+125°C@(Ta)
- Peak Output Current(sink): 2A
- Peak Output Current(source): 2A
- Package: DIP-8
- Manufacturer: Texas Instruments
- Channel Type: Synchronous
- Input Type: Non-Inverting
- Voltage - Supply: 4V ~ 14V
- Series: -
- Mounting Type: Through Hole
- Packaging: Tube
- Package / Case: 8-DIP (0.300", 7.62mm)
- Part Status: Active
- Logic Voltage - VIL, VIH: 1V, 4V
- Rise / Fall Time (Typ): 14ns, 15ns
- Gate Type: N-Channel, P-Channel MOSFET
- Base Part Number: TPS281
- Supplier Device Package: 8-PDIP
- Current - Peak Output (Source, Sink): 2A, 2A
- detail: Low-Side Gate Driver IC Non-Inverting 8-PDIP
