دیتاشیت MC34063ACN

MC34063xx

مشخصات دیتاشیت

نام دیتاشیت MC34063xx
حجم فایل 964.506 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت MC34063xx

MC34063xx Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: Buck-boost type
  • Topology: Step-down;Boost
  • Datasheet: STMicroelectronics MC34063ACN
  • Output Type: Adjustable
  • Input Voltage: 3V~40V
  • Output Voltage: 1.25V~38V
  • Number of Outputs: 1
  • Switching Frequency: 100kHz
  • Output Current (Max): 1.5A
  • Operating Temperature: 0°C~+70°C@(TA)
  • Synchronous Rectification: NO
  • Package: DIP-8
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive or Negative
  • Voltage - Input (Min): 3V
  • Voltage - Input (Max): 40V
  • Voltage - Output (Min/Fixed): 1.25V
  • Voltage - Output (Max): 38V
  • Current - Output: 1.5A (Switch)
  • Frequency - Switching: 33kHz
  • Synchronous Rectifier: No
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-DIP
  • Base Part Number: MC3406
