ADS831E Datasheet
Datasheet specifications
|
Datasheet's name
|
ADS831E
|
|
File size
|
86.549
KB
|
|
File type
|
pdf
|
|
Number of pages
|
17
|
Technical specifications
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Texas Instruments ADS831E
-
Interface:
Parallel
-
resolution:
8Bit
-
Supply Voltage:
5V
-
differential input:
Yes
-
number of channels:
1
-
sampling frequency:
80MHz
-
Operating Temperature:
-40°C~+85°C
-
Package:
SSOP-20
-
Manufacturer:
Texas Instruments
-
Architecture:
Pipelined
-
Input Type:
Differential, Single Ended
-
Series:
-
-
Ratio - S/H:ADC:
1:1
-
Packaging:
Tube
-
Data Interface:
Parallel
-
Reference Type:
External, Internal
-
Part Status:
Active
-
Supplier Device Package:
20-SSOP/QSOP
-
Number of A/D Converters:
1
-
Sampling Rate (Per Second):
80M
-
Configuration:
S/H-ADC
-
Package / Case:
20-SSOP (0.154", 3.90mm Width)
-
Mounting Type:
Surface Mount
-
Base Part Number:
ADS831
-
Features:
-
-
Number of Bits:
8
-
Number of Inputs:
1
-
Voltage - Supply, Analog:
5V
-
Voltage - Supply, Digital:
5V
-
detail:
8 Bit Analog to Digital Converter 1 Input 1 Pipelined 20-SSOP/QSOP
