دیتاشیت ADP1613ARMZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP1612-13
|
| حجم فایل |
1307.552
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost;SEPIC
-
Datasheet:
Analog Devices ADP1613ARMZ-R7
-
Output Type:
Adjustable
-
Input Voltage:
2.5V~5.5V
-
Output Voltage:
2.5V~20V
-
Number of Outputs:
1
-
Switching Frequency:
650kHz;1.3MHz
-
Output Current (Max):
2A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
MSOP-8
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.5V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
2.5V
-
Voltage - Output (Max):
20V
-
Current - Output:
2A (Switch)
-
Frequency - Switching:
650kHz, 1.3MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
8-MSOP
-
Base Part Number:
ADP1613
-
detail:
Boost, SEPIC Switching Regulator IC Positive Adjustable 2.5V 1 Output 2A (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
