دیتاشیت L6258EX

L6258E

مشخصات دیتاشیت

نام دیتاشیت L6258E
حجم فایل 363.161 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت L6258E

L6258E Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Motor Type - Stepper: Bipolar
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (4)
  • Interface: Parallel
  • Technology: DMOS
  • Step Resolution: 1, 1/2, 1/4, 1/8, 1/16
  • Applications: General Purpose
  • Current - Output: 1.2A
  • Voltage - Supply: 4.75V ~ 5.25V
  • Voltage - Load: 12V ~ 40V
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: PowerSO-36 Exposed Bottom Pad
  • Supplier Device Package: PowerSO-36
  • Base Part Number: L6258
  • detail: Bipolar Motor Driver DMOS Parallel PowerSO-36
