دیتاشیت CD4020BE

CD4020B/24B/40B Types

مشخصات دیتاشیت

نام دیتاشیت CD4020B/24B/40B Types
حجم فایل 1649.96 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت CD4020B/24B/40B Types

CD4020B/24B/40B Types Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Counters / Dividers
  • Datasheet: Texas Instruments CD4020BE
  • Direction: 向上计数器
  • Count Rate: 24MHz
  • Logic Type: Binary Counter
  • Reset Style: Asynchronous
  • Timing mode: -
  • Trigger Type: Negative Edge
  • Supply Voltage: 3V~18V
  • Number of Elements: 1
  • Operating Temperature: -55°C~+125°C
  • Number of Bits per Element: 14
  • Package: DIP-16
  • Manufacturer: Texas Instruments
  • Timing: -
  • Reset: Asynchronous
  • Voltage - Supply: 3V ~ 18V
  • Part Status: Active
  • Mounting Type: Through Hole
  • Packaging: Tube
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Series: 4000B
  • Supplier Device Package: 16-PDIP
  • Base Part Number: CD4020
