دیتاشیت STW60NE10

STW60NE10

مشخصات دیتاشیت

نام دیتاشیت STW60NE10
حجم فایل 294.196 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت STW60NE10

STW60NE10 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: STripFET™
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 100V
  • Current - Continuous Drain (Id) @ 25°C: 60A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 22mOhm @ 30A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 185nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 5300pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 180W (Tc)
  • Operating Temperature: 175°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: STW60N
  • detail: N-Channel 100V 60A (Tc) 180W (Tc) Through Hole TO-247-3
