دیتاشیت SN74LS155ANSR
مشخصات دیتاشیت
| نام دیتاشیت | SN54155-56, SN74155-56, SN54/74LS155A/156 |
|---|---|
| حجم فایل | 1278.605 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت SN54155-56, SN74155-56, SN54/74LS155A/156 |
SN54155-56, SN74155-56, SN54/74LS155A/156 Datasheet |
|---|
مشخصات
- RoHS: true
- Type: Decoder/Demultiplexers
- Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
- Datasheet: Texas Instruments SN74LS155ANSR
- Sink Current: 8mA
- Source Current: 400uA
- Supply Voltage: 4.75V~5.25V
- Operating temperature: 0°C~+70°C
- Voltage Supply Source: Single supply
- Package: SOP-16-208mil
- Manufacturer: Texas Instruments
- Series: 74LS
- Package / Case: 16-SOIC (0.209", 5.30mm Width)
- Supplier Device Package: 16-SO
- Circuit: 1 x 2:4
- Part Status: Active
- Current - Output High, Low: 400µA, 8mA
- Mounting Type: Surface Mount
- Independent Circuits: 2
- Voltage - Supply: 4.75V ~ 5.25V
- Packaging: Cut Tape (CT)
- Base Part Number: SN74LS15
- detail: Decoder/Demultiplexer 1 x 2:4 16-SO
