دیتاشیت HMC976LP3ETR
مشخصات دیتاشیت
| نام دیتاشیت |
HMC976LP3E
|
| حجم فایل |
1079.047
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Feature:
Thermal Protection
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices HMC976LP3ETR
-
Output Type:
Adjustable
-
Output Current:
400mA
-
Output Voltage:
1.8V~5V
-
Dropout Voltage:
-
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+85°C
-
Quiescent Current (Ground Current):
1.5mA
-
Power Supply Rejection Ratio (PSRR):
70dB@(1kHz),20dB@(50MHz)
-
Package:
QFN-16-EP(3x3)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
1.8V
-
Voltage - Output (Max):
5V
-
Voltage Dropout (Max):
-
-
Current - Output:
400mA
-
Current - Quiescent (Iq):
1.5mA
-
PSRR:
70dB ~ 20dB (1kHz ~ 50MHz)
-
Control Features:
Enable
-
Protection Features:
Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
16-VFQFN Exposed Pad
-
Supplier Device Package:
16-QFN (3x3)
-
Base Part Number:
HMC976
-
detail:
Linear Voltage Regulator IC 1 Output 400mA 16-QFN (3x3)
