AD7845JN Datasheet

AD7845

Datasheet specifications

Datasheet's name AD7845
File size 198.294 KB
File type pdf
Number of pages 12

Download Datasheet AD7845

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Number of Bits: 12
  • Number of D/A Converters: 1
  • Settling Time: 5µs
  • Output Type: Voltage - Buffered
  • Differential Output: No
  • Data Interface: Parallel
  • Reference Type: External
  • Voltage - Supply, Analog: ±14.25V ~ 15.75V
  • Voltage - Supply, Digital: -
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Architecture: R-2R
  • Operating Temperature: 0°C ~ 70°C
  • Package / Case: 24-DIP (0.300", 7.62mm)
  • Supplier Device Package: 24-PDIP
  • Mounting Type: Through Hole
  • Base Part Number: AD7845
