技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: FMS(Formosa Microsemi) SMBJ24A
- Breakdown Voltage: 26.7V
- Maximum Clamping Voltage: 38.9V
- Reverse Stand-Off Voltage (Vrwm): 24V
- Peak Pulse Current (Ipp)@10/1000us: 15.4A
- Package: SMB(DO-214AA)
- Manufacturer: FMS(Formosa Microsemi)
- Reverse Leakage Current (Ir): 1uA
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Bidirectional Channels: 1
- Peak Pulse Current (Ipp)@10/1000μs: 15.4A
- Unidirectional Channels: 1
- Peak Pulse Power Dissipation (Ppp)@10/1000μs: 600W
