2SC3320 Datasheet
Datasheet specifications
| Datasheet's name | 2SC3320 |
|---|---|
| File size | 1060.44 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet 2SC3320 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: SPTECH 2SC3320
- Transistor Type: NPN
- Operating Temperature: +150°C@(Tj)
- Collector Current (Ic): 15A
- Power Dissipation (Pd): 80W
- Transition Frequency (fT): -
- DC Current Gain (hFE@Ic,Vce): 10@6A,5V
- Collector Cut-Off Current (Icbo): 1mA
- Collector-Emitter Breakdown Voltage (Vceo): 400V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 1V@6A,1.2A
- Package: TO-3PN
- Manufacturer: SPTECH
