SMBJ28CA 数据手册
其他文档
SMBJ24A 4 pages
SMBJ24A 7 pages
SMBJ24A 4 pages
SMBJ24A 6 pages
SMBJ24A 5 pages
SMBJ24A 6 pages
SMBJ24A 5 pages
SMBJ24A 5 pages
SMBJ24A 6 pages
SMBJ24A 3 pages
SMBJ24A 5 pages
SMBJ24A 4 pages
SMBJ24A 4 pages
SMBJ24A 4 pages
SMBJ24A 4 pages
SMBJ24A 7 pages
SMBJ24A 5 pages
SMBJ24A 4 pages
SMBJ12A 6 pages
SMBJ12A 7 pages
SMBJ20A 6 pages
SMBJ20A 4 pages
SMBJ48CA 3 pages
SMBJ48CA 5 pages
SMBJ28CA 7 pages
SMBJ28CA 3 pages
SMBJ28CA 6 pages
SMBJ28CA 5 pages
SMBJ28CA 16 pages
SMBJ28CA 5 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: AnBon SMBJ28CA
- Breakdown Voltage: 31.1V
- Maximum Clamping Voltage: 45.4V
- Reverse Stand-Off Voltage (Vrwm): 28V
- Peak Pulse Current (Ipp)@10/1000us: 13.2A
- Package: SMB(DO-214AA)
- Manufacturer: AnBon
- Reverse Leakage Current (Ir): 1uA
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Peak Pulse Current (Ipp)@10/1000μs: 13.2A
- Bidirectional Channels: 1
- Unidirectional Channels: 0
