دیتاشیت 2SA1013
مشخصات دیتاشیت
| نام دیتاشیت |
2SA1013
|
| حجم فایل |
240.264
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
2
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
Jiangsu Changjing Electronics Technology Co., Ltd. 2SA1013
-
Transistor Type:
PNP
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
1A
-
Power Dissipation (Pd):
900mW
-
Transition Frequency (fT):
15MHz
-
DC Current Gain (hFE@Ic,Vce):
100@200mA,5V
-
Collector Cut-Off Current (Icbo):
1uA
-
Collector-Emitter Breakdown Voltage (Vceo):
160V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
1.5V@500mA,50mA
-
Package:
TO-92L
-
Manufacturer:
Jiangsu Changjing Electronics Technology Co., Ltd.
